Claude skill turns codebases into architecture diagrams

Architecture Diagram Generator is a lightweight open source Claude skill for turning a GitHub repo or local codebase into standalone HTML/SVG architecture diagrams fast. The workflow is simple: install the skill, point it at a project, and generate a clean visual without a heavier diagramming stack.

// ANALYSIS

Hot take: this is a strong tiny tool, immediate payoff release. The value is less about novelty and more about collapsing setup friction for a common documentation problem.

–Lightweight packaging makes it easy to import and reuse, which is the right shape for a Claude skill.
–The repo/local-project workflow targets real engineering use, especially for onboarding, reviews, and docs.
–Standalone HTML/SVG output is a practical choice because it is easy to share and embed.
–The main appeal is speed and convenience, not deep architectural reasoning or complex editable diagram tooling.
